eyePower Limited

eyePower Limited’s intelligent power distribution units are the PDU of choice for many broadcast companies, satellite uplinks, AV installers and more.

Offering unparalleled control of outlets using an inbuilt macro programming language or direct control from a web browser interface. Integration with management systems such as BNCS and Dataminer can be facilitated using an extensive API.

eyePower’s comprehensive monitoring of unit status and multiple electrical measurements offers customers an unrivalled insight into aspects of their electrical installation in a way not previously available.

Features | All units offer

• 16A powerCON inlet and 20A distribution
• 14 x IEC outlets fused at 3.15A, 10A capable
• Reliable components including linear PSU
• Low energy consumption 5.5W
• 7.5W max changeover
• Main supply measurements
• live/neutral 2500Vpk
• neutral/earth 2500Vpk
• imbalance 1mA – 5Arms
• frequency 45Hz – 65Hz
• Supply current 3mA – 70Apk
• Supply DC offset ±5V
• Power measurements (real and apparent)
• Outlet fuse status detect
• Monitoring of internal temperature and PSU ageing
• Front panel full colour OLED
• Front panel user programmable switch
• Comprehensive macro language for sequence programming
• Outlet relays with status detect
• RS422/485 with four GPIOs
• 1-Wire™ interface for environment sensors temperature, humidity, smoke
• 100Mbit/s Ethernet with PoE backup to monitor during mains supply failure

Options

• Dual inlets with Changeover on loss of active supply, measurements as main, monitored backfeed protection
• Outlet current measurement 3mA – 70Apk

Specifications

• Basic resolution of 1mA, 0.1V, 0.1W or 1W load dependent, 0.01Hz
• Voltage and current accuracy 1% for sinewave, power 2% PF>0.8
• Accuracy percentage +3 least significant digits voltage/current, +10 LSD power
• Imbalance (earth leakage) common mode rejection 99.5%

eyePower Limited manufactures extremely reliable and sophisticated electrical power distribution units. The company relies on the skills of two experienced engineers, Simon Quill and Chris Sims, who have worked together on intelligent power distribution since the 1990s.

Both Simon and Chris spent many years installing technical projects for high profile customers and appreciate the need for quality products with good manufacturer support. They are also aware that power distribution is capable of disabling multiple items of equipment. Units are designed for continuous service over a 10 to 20 year life.

Between 1994 and 2020, Simon held the senior technical role at Bryant Unlimited. Chris has worked as a consultant since leaving the BBC in 1994 and designed Bryant’s various generations of intelligent distribution.

As a family owned company, the closure of Bryant Unlimited at some point due to retirement was expected. Simon and Chris knew that they would continue the eyePower brand. While eyePower manufacture was busy during the events of 2020, the pandemic brought forward the closure of Bryant Unlimited after 35 years’ trading.

eyePower Limited are proud to continue with products that have been selected for the most prestigious projects. The operations such as PCB surface mount and painting continue with the same subcontractors. Every eyePower unit has been final tested by Simon or Chris and will be in the future.

For more information please feel free to Contact us
